a.Shangair series medium-pressure air compressors have excellent performance, stable operation, high efficiency and energy saving, and long service life.
b.The core "air valve part" of the air compressor adopts the "polygonal cylindrical DC valve" independently developed and designed. The air flow flows tangentially along the plane of the valve plate. long.
c.The new technology adopted by Shangair medium and high pressure air compressors has been tested and tested in various occasions for a long time: higher efficiency, higher reliability (24 hours uninterrupted and safe operation), longer life, lower noise and less vibration Small size, lower exhaust temperature, lower fuel consumption.
|
|
Model |
Power kw |
Discharge Air m3/min |
Working pressure Mpa |
Size L×W×Hmm |
Weight kg |
|
High pressure air compressor |
1.2/30 （with 0.15M3 air tank） |
11 |
1.2 |
3.0 |
1880×850×1050 |
580 |
|
1.2/30 |
11 |
1.2 |
3.0 |
1520×800×950 |
670 |
|
|
1.3/30 |
15 |
1.3 |
3.0 |
1650×1000×1000 |
650 |
|
|
1.6/3.0 |
18.5 |
1.6 |
3.0 |
1650×1000×1000 |
660 |
|
|
2.0/3.0 |
22 |
2.0 |
3.0 |
2170×1020×1050 |
680 |
|
|
2.4/30 |
2×11 |
2.4 |
3.0 |
1900×1600×1200 |
1200 |
|
|
2.6/30 |
2×15 |
2.6 |
3.0 |
2350×1100×1650 |
1120 |
|
|
3.2/30 |
2×18.5 |
3.2 |
3.0 |
2350×1100×1650 |
1150 |
|
|
4.0/3.0 |
2×22 |
4.0 |
3.0 |
3780×1100×1260 |
1550 |
|
|
4.8/30 |
3×18.5 |
4.8 |
3.0 |
3800×1000×1750 |
1750 |
|
|
6.0/3.0 |
3×22 |
6.0 |
3.0 |
5700×1100×1270 |
2520 |
|
|
6.4/30 |
4×18.5 |
6.4 |
3.0 |
4650×1200×1650 |
2360 |
|
|
10.0/3.0 |
5×22 |
10.0 |
3.0 |
9700×1100×1500 |
4350 |
